| Varenummer | ACX567AKM-7 |
| Mærke | SONY |
| Størrelse | 3.2 |
| Ansøgning | MPH |
| Løsning | 320×480 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | SONY |
| panel model | ACX567AKM-7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.2 inch |
| løsning | 320(RGB)×480 , HVGA |
| visningstilstand | Normally Black, Transflective |
| aktivt område | 44.16×66.24 mm |
| omrids | 49.86×75.19 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.)(Transmissive)17:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| indgangsspænding | 1.8/3.0V (Typ.)(VDD/VBATT) |
| Ansøgning | MPH |
