| Varenummer | DLC0430NZG-T-1 |
| Mærke | Other |
| Størrelse | 4.3 |
| Ansøgning | HHP |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 760 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | DLC |
| panel model | DLC0430NZG-T-1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2×4.98 mm |
| overflade | |
| lysstyrke | 760 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | HHP |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| DLC0430EZG-11 | Other | 4.3 | 480×272 |
| DLC0430LZG | Other | 4.3 | 480×272 |
| DLC0430LZG-6 | Other | 4.3 | 480×272 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| DLC0430LZG-T | Other | 4.3 | 480×272 |
| DLC0430NZG | Other | 4.3 | 480×272 |
| DLC0430NZG-T-1 | Other | 4.3 | 480×272 |
| G043FW01 V0 | AUO | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| 24QVW1H | SII | 2.4 | 240×320 |
| 30WQF0H | SII | 3.0 | 240×400 |
| AM-320480-035BT | Other | 3.5 | 320×480 |
| COM24H2N62XLC | ORTUSTECH | 2.4 | 240×320 |
| COM41H4M31XLC | ORTUSTECH | 4.1 | 320×240 |
| DLC0240ACOG-3 | Other | 2.4 | 240×320 |
| DLC0700WZG | Other | 7.0 | 1200×1920 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS037V7DW01 | SHARP | 3.7 | 480×640 |
