| Varenummer | LS013B4DN04 |
| Mærke | SHARP |
| Størrelse | 1.35 |
| Ansøgning | HHP |
| Løsning | 96×96 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Monochrome |
| Baggrundsbelysning | No B/L |
| Interface | SPI |
| panel mærke | SHARP |
| panel model | LS013B4DN04 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 1.35 inch |
| løsning | 96×96 |
| visningstilstand | PNLC, Reflective |
| aktivt område | 24.192×24.192 mm |
| omrids | 28.2×32.34 mm |
| overflade | Without Polarizer, Hard coating (3H) |
| lysstyrke | |
| kontrastforhold | 10:1 (Typ.)(Reflective) |
| vise farver | Monochrome |
| responstid | 50/50 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/60/60 (Min.)(CR≥3)(L/R/U/D) |
| lampe type | No B/L |
| signal interface | SPI, 10 pins |
| indgangsspænding | 3.0/3.0V (Typ.)(VDDA/VDD) |
| Ansøgning | HHP |
| LS013B4DN01 | SHARP | 1.35 | 96×96 |
| LS013B4DN02 | SHARP | 1.35 | 96×96 |
| LS013B4DN04 | SHARP | 1.35 | 96×96 |
| LS013B7DH01 | SHARP | 1.26 | 144×168 |
| LS013B7DH03 | SHARP | 1.28 | 128×128 |
| LS013B7DH05 | SHARP | 1.26 | 144×168 |
| LS013B7DH06 | SHARP | 1.33 | 128×128 |
| 28QVF1H | SII | 2.8 | 240×320 |
| CMD500TT10-C1 | ORTUSTECH | 3.2 | 320×240 |
| COM22H2P16ULC | ORTUSTECH | 2.2 | 240×320 |
| DLC0350AMG-4 | Other | 3.5 | 320×240 |
| LQ030B7UB02 | SHARP | 3.0 | 240×400 |
| LQ038Q7DB03A | SHARP | 3.8 | 240×320 |
| LS037V7DW03B | SHARP | 3.7 | 480×640 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TM035HDHT1 | Tianma | 3.5 | 240×320 |
