| Varenummer | DLC0200EUG |
| Mærke | Other |
| Størrelse | 2.0 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 90 |
| CR | 75:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | DLC |
| panel model | DLC0200EUG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.0 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 30.6×40.8 mm |
| omrids | 36.72×52.74×3.4 mm |
| overflade | |
| lysstyrke | 90 cd/m² (Typ.) |
| kontrastforhold | 75:1 (Typ.)(Transmissive) |
| vise farver | 262K (6-bit), CIE193130% |
| responstid | 33 (Typ.)(Tr+Td) |
| synsvinkel | 58/27/80/40 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S4PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 41 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | HHP |
