| Varenummer | COM35T3112DTR |
| Mærke | ORTUSTECH |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 100 |
| CR | 60:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CASIO |
| panel model | COM35T3112DTR |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 52.56×70.08 mm |
| omrids | 67.9×84.5×5.4 mm |
| overflade | |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 60:1 (Min.) |
| vise farver | 262K (6-bit) |
| responstid | 40/60 (Max.)(Tr/Td) |
| synsvinkel | 50/50/60/20 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 3.0V (Typ.) |
| Ansøgning | HHP |
