| Varenummer | EDTCB29QB0 |
| Mærke | Panasonic |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | Panasonic |
| panel model | EDTCB29QB0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Reflective |
| aktivt område | 211.2×158.4 mm |
| overflade | Antiglare (Haze 11%), Hard coating (2H) |
| lysstyrke | |
| kontrastforhold | 10:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 35/35/35/35 (Min.)(CR≥2)(L/R/U/D) |
| lampe type | No B/L |
| signal interface | LVDS (1 ch, 6-bit), 14 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
