| Varenummer | G121X1-L01 |
| Mærke | Innolux |
| Størrelse | 12.1 |
| Ansøgning | CNS |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 700:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | G121X1-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| omrids | 260.5×204×12.7 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 13/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| B121EW10 V0 | AUO | 12.1 | 1280×800 |
| G121X1-L01 | Innolux | 12.1 | 1024×768 |
| G121X1-L03 | Innolux | 12.1 | 1024×768 |
| G121X1-L04 | Innolux | 12.1 | 1024×768 |
| G121XN01 V0 | AUO | 12.1 | 1024×768 |
| G121XTN01.0 | AUO | 12.1 | 1024×768 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| LB121S1-A2 | LG Display | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| LQ12X12 | SHARP | 12.1 | 1024×768 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| CLAA070LF05CW | CPT | 7.0 | 800×480 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LQ035Q5DG11 | SHARP | 3.5 | 320×240 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| PM070WX5 | E Ink | 7.0 | 800×480 |
| YX090DKN01.0 | SEBO | 9.0 | 1280×720 |
