| Varenummer | G150XTN01.0 |
| Mærke | AUO |
| Størrelse | 15.0 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G150XTN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(2)×768(2) , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 326.5×253.5×13.1 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193160% |
| responstid | 5.7/2.3 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| G150XG01 V1 | AUO | 15.0 | 1024×768 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XTN01.0 | AUO | 15.0 | 1024×768 |
| G150XTN03.1 | AUO | 15.0 | 1024×768 |
| G150XTN06.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XTT01.0 | AUO | 15.0 | 1024×768 |
| AC150XA03 | Mitsubishi | 15.0 | 1024×768 |
| BA121S01-100 | BOE | 12.1 | 800×600 |
| BRS-320H02 | 32.0 | 1920×1080 | |
| G220SW02 V0 | AUO | 22.0 | 1680×1050 |
| KCG075VG2BE-G00 | Kyocera | 7.5 | 640×480 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ104V1DG5A | SHARP | 10.4 | 640×480 |
| NL8060BC26-28 | NLT | 10.4 | 800×600 |
| PD064VT5 | E Ink | 6.4 | 640×480 |
| RGS08096032WR001 | RiTdisplay | 0.80 | 96×32 |
