| Varenummer | BT043NHME601 |
| Mærke | BOE |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 360×600 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | BOE |
| panel model | BT043NHME601 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 4.3 inch |
| løsning | 360(RGB)×600 , nHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 55.62×92.7 mm |
| omrids | 59.4×101.9 mm |
| overflade | Without Polarizer |
| glas dybde | 0.30+0.30 mm |
| transmissivitet | 4.8% (Typ.)(with Polarizer) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| Ansøgning | MPH |
