| Varenummer | H466TAN01.1 |
| Mærke | AUO |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | AUO |
| panel model | H466TAN01.1 |
| paneltype | LTPS TFT-LCD , CELL |
| panelstørrelse | 4.7 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 58.104×103.296 mm |
| omrids | 60.9×111.87 mm |
| overflade | Hard coating |
| glas dybde | 0.17+0.17 mm |
| transmissivitet | 3.9% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193166% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| driver ic | COG Built-in NT35590 |
