| Varenummer | H466TAN02.4 |
| Mærke | AUO |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | AUO |
| panel model | H466TAN02.4 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 4.7 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 58.104×103.296 mm |
| omrids | 60.9×111.87 mm |
| overflade | Hard coating |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 4.5% (Min.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | COG Built-in R61308 |
| Ansøgning | MPH |
| AMS369FG03-002 | Samsung | 3.7 | 480×800 |
| AMS429QC08 | Samsung | 4.3 | 540×960 |
| BS055FHE-N30-6Q00 | BOE | 5.5 | 1080×1920 |
| BTL507212-W677L | BOE | 5.0 | 720×1280 |
| CLAF040LE21 AX | CPT | 4.0 | 480×800 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| LH500X01-SD01 | LG Display | 5.0 | 768×1024 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TM035PDZ00 | Tianma | 3.5 | 320×480 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
