| Varenummer | HSD050FMW2-D00 |
| Mærke | HannStar |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | HannStar |
| panel model | HSD050FMW2-D00 2 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.0 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | IPS Pro, Normally Black, Transmissive |
| aktivt område | 62.046×110.304 mm |
| omrids | 65.1×117.9×0.4 mm |
| overflade | Without Polarizer |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 3.82% (Typ.)(with Polarizer) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | COG Suggest NT35516, NT35517, HX8389-B, RM68190, OTM9608A, OTM9605A |
| Ansøgning | MPH |
