| Varenummer | TM050QDH11 |
| Mærke | Tianma |
| Størrelse | 5.0 |
| Ansøgning | VOIP |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TIANMA |
| panel model | TM050QDH11 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 101.568×76.176 mm |
| omrids | 117.35×88.43×15 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S5PWLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | VOIP |
