| Varenummer | HSD050I551-A00 |
| Mærke | HannStar |
| Størrelse | 5.0 |
| Ansøgning | VDP |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 350:1 |
| Farver | |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | HannStar |
| panel model | HSD050I551-A00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 102.72×74.53 mm |
| omrids | 119.3×91.4×7.8 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL) |
| rohs: | |
| Ansøgning | VDP |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| BTL507212-W749L | BOE | 5.0 | 720×1280 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| EJ050NA-01G | Innolux | 5.0 | 800×480 |
| HSD050I551-A00 | HannStar | 5.0 | 320×234 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| HSD050IDW1-A30 | HannStar | 5.0 | 800×480 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| YX050800480WTIPS | 5.0 | 800×480 | |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| CLAA070WA03 | CPT | 7.0 | 480×234 |
| LB065W01-B11B | LG Display | 6.5 | 400×234 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| PW070DS1T6 | E Ink | 7.0 | 480×234 |
| TM056KDH02 | Tianma | 5.6 | 320×234 |
