| Varenummer | PW056XU1 |
| Mærke | E Ink |
| Størrelse | 5.5 |
| Ansøgning | VDP |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PW056XU1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 121.68×68.45 mm |
| omrids | 136×82.6×6.1 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 30 pins |
| indgangsspænding | 3.3/3.3/5.0/17.0/12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| Ansøgning | VDP |
