| Varenummer | BTL507212-W749L |
| Mærke | BOE |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BTL507212-W749L |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 62.1×110.4 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 27 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
