| Varenummer | HSD123JPW3-A10 |
| Mærke | HannStar |
| Størrelse | 12.3 |
| Ansøgning | Outdoor High Brightn |
| Løsning | 1920×720 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 11S4P |
| Interface | LVDS |
| fabrikant | HannStar |
| modelnavn | HSD123JPW3-A10 |
| skærmstørrelse | 12.3 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 292.032 × 109.512 (H×V) |
| omrids (mm) | 302 × 125.4 × 14.2 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Glare (Haze 0%), Hard coating |
| luminans | 850 cd/m² (Typ.) |
| kontrastforhold | 1500 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 25 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS Pro, Normally Black, Transmissive |
| farvedybde | 16.7M 75% NTSC |
| baggrundsbelysning | 11S4P WLED , 30K hours , No Driver |
| masse | 345/378g (Typ./Max.) |
| anvendes til | Outdoor High Brightness Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (2 ch, 8-bit) , Connector 50 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
