| Varenummer | HSD123KPW2-A10 |
| Mærke | HannStar |
| Størrelse | 12.3 |
| Ansøgning | Automotive Display |
| Løsning | 1920×720 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1100:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 11S4P |
| Interface | LVDS |
| fabrikant | HannStar |
| skærmstørrelse | 12.3 inch |
| pixel antal | 1920(RGB)×720 167PPI |
| aktivt område (mm) | 292.032 × 109.512 (H×V) |
| rammeareal (mm) | 294.8 × 112.1 (H×V) |
| luminans | 850 cd/m² (Typ.) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 16.7M 70% NTSC |
| masse | TBD |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (2 ch, 8-bit) , 50 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| modelnavn | HSD123KPW2-A10 |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| behandling | Glare (Haze 0%) |
| kontrastforhold | 1100 : 1 (Typ.) (TM) |
| respons | 16/14 (Typ.)(Tr/Td) ms |
| arbejdstilstand | IPS Pro, Normally Black, Transmissive |
| baggrundsbelysning | 11S4P WLED , 30K hours , No Driver |
| anvendes til | Automotive Display |
| berøringsskærm | Without |
