| Varenummer | LA123WF4-SR03 |
| Mærke | LG Display |
| Størrelse | 12.3 |
| Ansøgning | Automotive Display |
| Løsning | 1920×720 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | RSDS |
| mærke | LG Display |
| model | LA123WF4-SR03 |
| diagonal størrelse | 12.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×720 167PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 292.032(H)×109.512(V) mm |
| omrids dim. | 310(H)×128(V) ×10.75(D) mm |
| bezel område | 296.03(H)×113.5(V) mm |
| behandling | Hard coating |
| luminans | 600 cd/m² (Min.) |
| kontrastforhold | 800:1 (Min.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 16.7M 77% NTSC |
| lyskilde | WLED [11S4P] , 10K hours , W/O Driver |
| vægt | 385/400g (Typ./Max.) |
| designet til | Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | RSDS (2 Channel) , 110 pins FPC |
| Strømforsyning | 3.3/13.0V (Typ.)(VCC/VDD) |
| miljø | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
