| Varenummer | LA123WF4-SR08 |
| Mærke | LG Display |
| Størrelse | 12.3 |
| Ansøgning | Automotive Display |
| Løsning | 1920×720 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 8S6P |
| Interface | |
| fabrikant | LG Display |
| modelnavn | LA123WF4-SR08 |
| skærmstørrelse | 12.3 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 292.032 × 109.512 (H×V) |
| omrids (mm) | 310 × 128 × 10.75 (H×V×D) |
| rammeareal (mm) | 296.03 × 113.5 (H×V) |
| behandling | Hard coating |
| luminans | 600 cd/m² (Min.) |
| kontrastforhold | 800 : 1 (Min.) (TM) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10) |
| respons | 30 (Max.)(G to G); 30 (Typ.)(MPRT) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| farvedybde | 16.7M 77% NTSC |
| baggrundsbelysning | 8S6P WLED , 10K hours , No Driver |
| masse | - |
| anvendes til | Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
