| Varenummer | L5S30883P00 |
| Mærke | SANYO |
| Størrelse | 4.5 |
| Ansøgning | CNS |
| Løsning | 480×240 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SANYO |
| panel model | L5S30883P00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.5 inch |
| løsning | 480(RGB)×240 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 99.36×56.04 mm |
| omrids | 112.7×70.2 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
