| Varenummer | LK235D3HA0S |
| Mærke | SHARP |
| Størrelse | 23.6 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 5000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | Mini LVDS |
| panel mærke | SHARP |
| panel model | LK235D3HA0S |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 23.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 521.28×293.22 mm |
| omrids | 532.875×303.7 mm |
| overflade | Antiglare (Haze 2%), Hard coating (3H) |
| transmissivitet | 4.5% (Typ.)(with Polarizer) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 4 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 240Hz |
| signal interface | Mini LVDS, 160 pins |
| Ansøgning | DMPC |
