| Varenummer | MT215DW01 V.1 |
| Mærke | Innolux |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | MT215DW01 V.1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×268.11 mm |
| omrids | 495.6×292.2×10.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193170% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| HM215WU3-100 | BOE | 21.5 | 1920×1080 |
| HM215WU3-101 | BOE | 21.5 | 1920×1080 |
| HR215WU1-100 | BOE | 21.5 | 1920×1080 |
| LC215EUN-SCA1 | LG Display | 21.5 | 1920×1080 |
| LM215DT8A | PANDA | 21.5 | 1920×1080 |
| M215H1-L03 | Innolux | 21.5 | 1920×1080 |
| M215HW02 V0 | AUO | 21.5 | 1920×1080 |
| MT215DW01 V.0 | Innolux | 21.5 | 1920×1080 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| T215HVN01.0 | AUO | 21.5 | 1920×1080 |
| LM230WF3-SLQ1 | LG Display | 23.0 | 1920×1080 |
| LM240WU4-SLB1 | LG Display | 24.0 | 1920×1200 |
| LM340UW2-SSA1 | LG Display | 34 | 3440×1440 |
| LTM150XS-T01 | Samsung | 15.0 | 1024×768 |
| LTM220MT09 | Samsung | 22.0 | 1680×1050 |
| M185XW01 V5 | AUO | 18.5 | 1366×768 |
| M190PW01 V0 | AUO | 19.0 | 1440×900 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| M320QAN01.0 | AUO | 32.0 | 3840×2160 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
