| Varenummer | LM038QC1R10 |
| Mærke | SHARP |
| Størrelse | 3.8 |
| Ansøgning | HHP |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Color |
| Baggrundsbelysning | No B/L |
| Interface | Parallel Data |
| panel mærke | SHARP |
| panel model | LM038QC1R10 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | STN, Normally Black, Reflective |
| aktivt område | 76.8×57.6 mm |
| omrids | 96.6×72.4 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 10:1 (Typ.)(Reflective) |
| vise farver | Color |
| responstid | 230/120 (Typ.)(Tr/Td) |
| synsvinkel | 20/20/30/30 (Typ.)(CR>2)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | No B/L |
| signal interface | Parallel Data (8-bit), 24 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | HHP |
