| Varenummer | LQ030B7UB02 |
| Mærke | SHARP |
| Størrelse | 3.0 |
| Ansøgning | HHP |
| Løsning | 240×400 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 100:1 |
| Farver | 65K/262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | SHARP |
| panel model | LQ030B7UB02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 240(RGB)×400 , WQVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 38.88×64.8 mm |
| omrids | 47.28×76.4 mm |
| overflade | Hard coating (3H), Antireflection |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| vise farver | 65K/262K |
| responstid | 30/30 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/65/50 (Typ.)(CR≥2)(L/R/U/D) |
| lampe type | 6S1PWLED |
| signal interface | CPU/RGB/SPI, 45 pins |
| Ansøgning | HHP |
