| Varenummer | PD035VX2 |
| Mærke | E Ink |
| Størrelse | 3.5 |
| Ansøgning | PND |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | PVI |
| panel model | PD035VX2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 72×52.56 mm |
| omrids | 84.03×65.24 mm |
| overflade | Antiglare |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S2PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 50 pins |
| indgangsspænding | 3.3/3.3/10/17/-10V (Typ.)(VCC/VDD/VDD1/VCG/VEE) |
| Ansøgning | PND |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LS035Y8DX04A | SHARP | 3.5 | 480×800 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| PD035VX2 | E Ink | 3.5 | 640×480 |
| PD035VX8 | E Ink | 3.5 | 480×640 |
| PD035VX9 | E Ink | 3.5 | 480×640 |
| 43WVF0H | SII | 4.3 | 800×480 |
| 990000475 | TPO | 4.3 | 800×480 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| DLC0500HZG-T-8 | Other | 5.0 | 800×480 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| TS40WD2B-03 | Other | 4.0 | 480×272 |
