| Varenummer | LP097QX3-SPAV |
| Mærke | LG Display |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 1536×2048 |
| Sammensætning | Assembly |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP097QX3-SPAV |
| paneltype | a-Si TFT-LCD , Assembly |
| panelstørrelse | 9.7 inch |
| løsning | 1536(RGB)×2048 , QXGA |
| aktivt område | 147.456×196.608 mm |
| omrids | 167.094×237.618×5.3 mm |
| overflade | Glare (Haze 0%), Hard coating (3H), Antireflection |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | eDP (4 Lanes), 60 pins |
| indgangsspænding | 3.7V (Typ.) |
| Ansøgning | PAD |
