| Varenummer | LP104S2 |
| Mærke | LG Display |
| Størrelse | 10.4 |
| Ansøgning | NBPC |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 70 |
| CR | 100:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | LG Electronics |
| panel model | LP104S2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 246.5×179.4 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 70 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 30/50 (Max.)(Tr/Td) |
| synsvinkel | 40/40/10/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 41 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | NBPC |
