| Varenummer | LQ065T5AR05 |
| Mærke | SHARP |
| Størrelse | 6.5 |
| Ansøgning | CNS |
| Løsning | 400×234 |
| Sammensætning | LCM |
| Lysstyrke | 420 |
| CR | 100:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | SHARP |
| panel model | LQ065T5AR05 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 400(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 143.4×79.326 mm |
| omrids | 155×89.2 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 420 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Typ.) |
| vise farver | Full color |
| responstid | 30/50 (Typ.)(CR≥10) |
| synsvinkel | 50/50/35/55 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog, 30 pins |
| indgangsspænding | 12.0V (Typ.)(VIN) |
| Ansøgning | CNS |
| LQ065T5AR05 | SHARP | 6.5 | 400×234 |
| LQ065T5BR08 | SHARP | 6.5 | 400×240 |
| LQ065T5DG05 | SHARP | 6.5 | 480×234 |
| LQ065T5DG30 | SHARP | 6.5 | 400×240 |
| LQ065T5GA01 | SHARP | 6.5 | 400×234 |
| LQ065T5GG63 | SHARP | 6.5 | 400×234 |
| LQ065T9BR51U | SHARP | 6.5 | 400×240 |
| LQ065T9DR51U | SHARP | 6.5 | 400×240 |
| LQ065Y5DG01 | SHARP | 6.5 | 800×480 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| A070FW01 | AUO | 7.0 | 480×234 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| LQ070T5DR01 | SHARP | 7.0 | 480×240 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LQ101K5DZ01 | SHARP | 10.1 | 1280×422 |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PA080XS4 | E Ink | 7.9 | 480×468 |
| TX15D02VM0CAA | KOE | 5.8 | 400×240 |
