| Varenummer | LQ079L1SX02 |
| Mærke | SHARP |
| Størrelse | 7.9 |
| Ansøgning | PAD |
| Løsning | 1536×2048 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LQ079L1SX02 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 7.9 inch |
| løsning | 1536(RGB)×2048 , QXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 119.808×159.744 mm |
| omrids | 125.55×170.95 mm |
| overflade | Clear, Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S4PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 50 pins |
| indgangsspænding | 1.8/5.6/-5.6V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | PAD |
