| Varenummer | LS013B4DN02 |
| Mærke | SHARP |
| Størrelse | 1.35 |
| Ansøgning | |
| Løsning | 96×96 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Monochrome |
| Baggrundsbelysning | No B/L |
| Interface | SPI |
| panel mærke | SHARP |
| panel model | LS013B4DN02 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 1.35 inch |
| løsning | 96×96 |
| visningstilstand | PNLC, Reflective |
| aktivt område | 24.192×24.192 mm |
| omrids | 28.2×31.64 mm |
| overflade | Without Polarizer, Hard coating (3H) |
| lysstyrke | |
| kontrastforhold | 10:1 (Typ.)(Reflective) |
| vise farver | Monochrome |
| responstid | 50/50 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/60/60 (Typ.)(CR≥3)(L/R/U/D) |
| lampe type | No B/L |
| signal interface | SPI, 10 pins |
| indgangsspænding | 5.0/5.0V (Typ.)(VDDA/VDD) |
| LS013B4DN01 | SHARP | 1.35 | 96×96 |
| LS013B4DN02 | SHARP | 1.35 | 96×96 |
| LS013B4DN04 | SHARP | 1.35 | 96×96 |
| LS013B7DH01 | SHARP | 1.26 | 144×168 |
| LS013B7DH03 | SHARP | 1.28 | 128×128 |
| LS013B7DH05 | SHARP | 1.26 | 144×168 |
| LS013B7DH06 | SHARP | 1.33 | 128×128 |
| DLC0104AZOG | Other | 1.0 | 128×32 |
| LMS430HF01-013 | Samsung | 4.3 | |
| LQ056A3AG01R | SHARP | 5.6 | 320×234 |
| LTA070B2C0F | TOSHIBA | 7.0 | |
| LTA150B850F | TOSHIBA | 15.0 | 1024×768 |
| LTV035QV-F04 | Samsung | 3.5 | 320×240 |
| OEL9M5003-B-E | Other | 2.7 | 128×64 |
| P50AD4 | E Ink | 5.0 | 320×234 |
| SC2002A | Other | 2.9 | 20×2 |
| TY05001C0-40 V1 | Other | 5.0 | 800×480 |
