| Varenummer | H497TLB01 |
| Mærke | AUO |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | OLED |
| Lysstyrke | 250 |
| CR | 10000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | |
| panel mærke | AUO |
| panel model | H497TLB01 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 5.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| aktivt område | 61.92×110.08 mm |
| omrids | 65.92×118.64×0.87 mm |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| synsvinkel | 80/80/80/80 (Min.)(CR≥200)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Suggest RM69052 |
| Ansøgning | MPH |
