| Varenummer | M121GNX2 R1 |
| Mærke | IVO |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | M121GNX2 R1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.76×184.32 mm |
| omrids | 279×209×9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 8-bit), CIE193172% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 stringsWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| B121EW09 V0 | AUO | 12.1 | 1280×800 |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| HSD121PS11-A | HannStar | 12.1 | 800×600 |
| LT121EE16000 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EWPF | TOSHIBA | 12.1 | 1280×800 |
| LTM12C289 | TOSHIBA | 12.1 | 800×600 |
| LTM12C505D | TOSHIBA | 12.1 | 1024×768 |
| M121GNX2 R1 | IVO | 12.1 | 1024×768 |
| NL8060BC31-41E | NLT | 12.1 | 800×600 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| AA104VC02 | Mitsubishi | 10.4 | 640×480 |
| G156HTN02.0 | AUO | 15.6 | 1920×1080 |
| LT121EE01000 | TOSHIBA | 12.1 | 1280×800 |
| LTA084C270F | TOSHIBA | 8.4 | 800×600 |
| NL10260BC19-01D | NLT | 8.9 | 1024×600 |
| NL12876BC26-25 | NLT | 15.3 | 1280×768 |
| PD050VX2 | E Ink | 5.0 | 480×640 |
| TCG058QVLAA-G00 | Kyocera | 5.8 | 320×240 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
