| Varenummer | MCT-G320240DTCW-151N |
| Mærke | TRULY |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 320×240 |
| Sammensætning | CSTN-LCD , LCM |
| Lysstyrke | |
| CR | 45:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel |
| mærke | TRULY |
| diagonal størrelse | 5.7 inch |
| pixel format | 320(RGB)×240 [QVGA] 70PPI |
| aktivt område | 115.18(H)×86.38(V) mm |
| bezel område | 119.18(H)×90.38(V) mm |
| luminans | 220 cd/m² (Typ.) |
| visningsretning | - |
| synsvinkel | 50/50/55/40 (Typ.)(CR≥10) |
| støtte farve | Color |
| vægt | - |
| billedhastighed | - |
| interface type | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| model | MCT-G320240DTCW-151N |
| type | CSTN-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 158.5(H)×109(V) ×9.2(D) mm |
| behandling | - |
| kontrastforhold | 45:1 (Typ.) (TM) |
| responstid | 215/110 (Typ.)(Tr/Td) |
| driftstilstand | STN, Normally Black, Transmissive |
| lyskilde | CCFL [1 pcs] , 15K hours , W/O Driver |
| designet til | Industrial |
| berøringspanel | Without |
| AG-320240A4FIQW-K9H-S(N)(R) | AMPIRE | 5.7 | 320×240 |
| DLC0570BDG-T-2 | Other | 5.7 | 640×480 |
| DLC0570FDG | Other | 5.7 | 320×240 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| SP14Q001-X | KOE | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
| TX14D22VM1BAA | KOE | 5.7 | 320×240 |
