| Varenummer | MT215DW01 V.0 |
| Mærke | Innolux |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | MT215DW01 V.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×268.11 mm |
| omrids | 495.6×292.2×16.85 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| G215HVN01.0 S03 | AUO | 21.5 | 1920×1080 |
| LC215DT4A | PANDA | 21.5 | 1920×1080 |
| LM215WF3-SLA2 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| M215HGE-L21 | Innolux | 21.5 | 1920×1080 |
| M215HGK-L30 | Innolux | 21.5 | 1920×1080 |
| M215HW02 V0 | AUO | 21.5 | 1920×1080 |
| MT215DW01 V.0 | Innolux | 21.5 | 1920×1080 |
| MT215DW01 V.1 | Innolux | 21.5 | 1920×1080 |
| RX215-C10 | ROGIN | 21.5 | 1920×1080 |
| LM171WX3-TLC1 | LG Display | 17.1 | 1440×900 |
| LM230WF1-TLA3 | LG Display | 23.0 | 1920×1080 |
| LM260WU2-SLA1 | LG Display | 25.5 | 1920×1200 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| LTM200KP01 | Samsung | 20.0 | 1600×900 |
| LTM230HT01 | Samsung | 23.0 | 1920×1080 |
| M150XS03 V1 | AUO | 15.0 | 1024×768 |
| M156B3-L01 | Innolux | 15.6 | 1366×768 |
| M170EN01 V9 | AUO | 17.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
