| Varenummer | NL10276BC30-17 |
| Mærke | NLT |
| Størrelse | 15.0 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL10276BC30-17 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | UA-SFT, Normally Black, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 326.5×253.5×17 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 14/11 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| NL10276AC24-05 | NLT | 12.1 | 1024×768 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| NL10276BC16-06 | NLT | 8.4 | 1024×768 |
| NL10276BC20-08 | NLT | 10.4 | 1024×768 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-15 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| LM-EH53-22NTK | SANYO | 10.4 | 640×480 |
| LM290WW2-SSA1 | LG Display | 29.0 | 2560×1080 |
| LM32C041 | SHARP | 5.5 | 320×240 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| RGS27128064YW000 | RiTdisplay | 2.7 | 128×64 |
| UG-2864ASGPG01 | WiseChip | 2.4 | 128×64 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| UG-9616TLBBG01 | WiseChip | 0.84 | 96×16 |
