| Varenummer | NV156FHM-N52 |
| Mærke | BOE |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | |
| mærke | BOE |
| model | NV156FHM-N52 (BOE0847) 4 Compatible |
| diagonal størrelse | 15.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1920(RGB)×1080 [FHD] 141PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 344.16(H)×193.59(V) mm |
| omrids dim. | 350.66(H)×205.84(V) ×4.6(D) mm |
| bezel område | - |
| behandling | Glare (Haze 0%), Hard coating (3H) |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | ADS, Normally Black, Transmissive |
| støtte farve | 1.07B 72% NTSC |
| lyskilde | WLED [11S4P] , 15K hours , With LED Driver |
| form stil | Slim (PCBA Bent, T≤3.0mm) |
| designet til | Laptop |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
