| Varenummer | LS035Y8DX02A |
| Mærke | SHARP |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LS035Y8DX02A |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | ASV, Normally Black, Transflective |
| aktivt område | 45.36×75.6 mm |
| omrids | 51.16×86.45 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 11/24 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDIO/VCC) |
| Ansøgning | MPH |
