| Varenummer | TD030WHEA1 |
| Mærke | TPO |
| Størrelse | 3.0 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | TD030WHEA1 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 60×45 mm |
| omrids | 70.2×51.7 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DSC |
| 30WQF0H | SII | 3.0 | 240×400 |
| 990001086 | Innolux | 3.0 | |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| C-51505NFQJ-LB-AJN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LW-ALN | Kyocera | 3.0 | 20×2 |
| C030DW01 V0 | AUO | 3.0 | 320×240 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TD030WHEA1 | TPO | 3.0 | 320×240 |
| TFTMD030035 | JDI | 3.0 | 640×480 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| ACX385AKM-7 | SONY | 2.5 | 640×240 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| LMS350GF07-005 | Samsung | 3.5 | 320×240 |
| LTV250QV-F0A | Samsung | 2.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
