| Varenummer | TM050QDH06 |
| Mærke | Tianma |
| Størrelse | 5.0 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TIANMA |
| panel model | TM050QDH06 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 101.568×76.176 mm |
| omrids | 113.6×88.4×10 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (6-bit + Dithering), CIE193150% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S5PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3/5.0/15.0/-8.2V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansøgning | IA |
| PA050DS4 | E Ink | 5.0 | 320×234 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
| TM050QDH01 | Tianma | 5.0 | 640×480 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
| TM050QDH07 | Tianma | 5.0 | 640×480 |
| TM050QDH11 | Tianma | 5.0 | 640×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| EL160.80.50 ET | Lumineq | 3.5 | 160×80 |
| G085VW01 V2 | AUO | 8.5 | 800×480 |
| G321EV5R000 | SII | 4.7 | 320×240 |
| HSD121MS11-A | HannStar | 12.1 | 800×600 |
| LM12S471 | SHARP | 12.1 | 800×600 |
| M203-L8A | NAN YA | 5.7 | 320×240 |
| MD286TT00-C1 | ORTUSTECH | 10.4 | 640×480 |
| PD104SLG | E Ink | 10.4 | 800×600 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
