| Varenummer | TM050LDZ00 |
| Mærke | Tianma |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 240×400 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 200:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | TIANMA |
| panel model | TM050LDZ00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 240(RGB)×400 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 65.16×108.6 mm |
| omrids | 76.3×123.4×12.9 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Min.) |
| kontrastforhold | 200:1 (Min.) |
| vise farver | 262K (6-bit), CIE193170% |
| responstid | 40 (Max.)(Tr+Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S10PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6/8-bit) + SPI, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
