| Varenummer | TM123XDHP90 |
| Mærke | TIANMA |
| Størrelse | 12.3 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1920×720 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 10S4P |
| Interface | LVDS |
| panel mærke | TIANMA |
| panel model | TM123XDHP90 |
| panelstørrelse | 12.3" |
| paneltype | a-Si TFT-LCD, LCM |
| løsning | 1920(RGB)×720, 166PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 292.32(W)×109.62(H) mm |
| bezel åbning | - |
| konturstørrelse | 311(W)×130(H) ×15.7(D) mm |
| overflade | Antiglare (Haze 28%) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| synsvinkel | - |
| visningstilstand | SFT, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| vise farver | 16.7M 98% sRGB |
| lampe type | 10S4P WLED , 10K hours , Without Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| panelvægt | 490g (Typ.) |
| Ansøgning | Industrial Outdoor High Brightness Automotive Display |
| signal interface | LVDS (2 ch, 8-bit) , 50 pins FPC |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
