| Varenummer | TPM0501010P |
| Mærke | JDI |
| Størrelse | 5.0 |
| Ansøgning | Mobile Phone |
| Løsning | 1080×1920 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| mærke | JDI |
| model | TPM0501010P |
| diagonal størrelse | 5.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1080(RGB)×1920 [FHD] 445PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 61.641(H)×109.584(V) mm |
| omrids dim. | 64.04(H)×116.52(V) ×1.48(D) mm |
| luminans | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 16.7M 85% NTSC |
| lyskilde | WLED [7S2P] , W/O Driver |
| vægt | TBD |
| designet til | Mobile Phone |
| billedhastighed | 60Hz |
| berøringspanel | In-Cell Touch |
| interface type | MIPI (4 data lanes) , 40 pins Connector |
| Strømforsyning | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| miljø | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
