| Varenummer | EE050NA-04A |
| Mærke | Innolux |
| Størrelse | 5.0 |
| Ansøgning | VDP |
| Løsning | 640×480 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | TTL |
| panel mærke | CHIMEI INNOLUX |
| panel model | EE050NA-04A |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.0 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 101.568×76.176 mm |
| omrids | 109.55×85.86 mm |
| overflade | Antiglare |
| glas dybde | 0.63+0.63 mm |
| transmissivitet | 5.5% (Typ.)(with Polarizer) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | VDP |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| AT050TN35 | Innolux | 5.0 | 480×272 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| P50AD4 | E Ink | 5.0 | 320×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| TM050JVZG28 | Tianma | 5.0 | 720×1280 |
| A056DN01 | AUO | 5.6 | 320×234 |
| A056DN01 V2 | AUO | 5.6 | 320×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| EE050NA-04A | Innolux | 5.0 | 640×480 |
| HSD050I551-A00 | HannStar | 5.0 | 320×234 |
| HSD070I651-C02 | HannStar | 7.0 | 480×234 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
