| Varenummer | VVX07H005A10 |
| Mærke | Panasonic |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | Panasonic |
| panel model | VVX07H005A10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.2×150.72 mm |
| omrids | 104.32×161.67×3.6 mm |
| overflade | Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S5PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 34 pins |
| indgangsspænding | 3.3/1.8V(Typ.) (VDD/VCC) |
| Ansøgning | PAD |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| M070SWP1 R5 | IVO | 7.0 | 800×480 |
| TD070WGCB1 | TPO | 7.0 | 854×480 |
| VVX07H005A00 | Panasonic | 7.0 | 800×1280 |
| VVX07H005A10 | Panasonic | 7.0 | 800×1280 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| LP079X01-SMAV | LG Display | 7.9 | 768×1024 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| TV080WXM-NL0 | BOE | 8.0 | 800×1280 |
| VVX07H005A90 | Panasonic | 7.0 | 800×1280 |
