| Varenummer | AT102TN03 V.1 |
| Mærke | Innolux |
| Størrelse | 10.2 |
| Ansøgning | DPF |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | INNOLUX |
| panel model | AT102TN03 V.1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.2 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 222×132.48 mm |
| omrids | 235×145.8×6.4 mm |
| overflade | Antiglare |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S13PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/9.2/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | DPF |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.3 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| C102EVN01.0 | AUO | 10.2 | 1280×720 |
| CLAA102NA01CW | CPT | 10.2 | 1024×600 |
| CLAA102NB01XV | CPT | 10.2 | 1024×600 |
| EZ102AT011 | PDI | 10.2 | 1024×1280 |
| TX26D89VM2BAA | KOE | 10.2 | 800×256 |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| HSD101PFW2-A00 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
