| Varenummer | AM-800480BDTZQW-00H |
| Mærke | AMPIRE |
| Størrelse | 4.3 |
| Ansøgning | Industrial Automotiv |
| Løsning | 800×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | Parallel |
| mærke | AMPIRE |
| model | AM-800480BDTZQW-00H |
| diagonal størrelse | 4.3 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 216PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 95.04(H)×53.856(V) mm |
| omrids dim. | 105.3(H)×67(V) mm |
| bezel område | 97.9(H)×56.7(V) mm |
| behandling | - |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | Normally Black, Transmissive |
| støtte farve | 16.2M |
| lyskilde | WLED [6S2P] , 50K hours , W/O Driver |
| vægt | - |
| designet til | Industrial Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
