| Varenummer | AM-800480D1TMQW-00H |
| Mærke | AMPIRE |
| Størrelse | 8.0 |
| Ansøgning | Industrial Automotiv |
| Løsning | 800×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| mærke | AMPIRE |
| model | AM-800480D1TMQW-00H |
| diagonal størrelse | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 116PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 176.64(H)×99.36(V) mm |
| omrids dim. | 192.8(H)×116.9(V) ×6.7(D) mm |
| bezel område | 180.1(H)×103.4(V) mm |
| behandling | Antiglare |
| luminans | 450 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) (TM) |
| visningsretning | - |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K/16.7M |
| lyskilde | WLED , 20K hours , W/O Driver |
| vægt | 251g (Typ.) |
| designet til | Industrial Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
