| Varenummer | AM-800480LTMQW-WAH |
| Mærke | AMPIRE |
| Størrelse | 5.0 |
| Ansøgning | Industrial |
| Løsning | 800×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| mærke | AMPIRE |
| model | AM-800480LTMQW-WAH |
| diagonal størrelse | 5.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 188PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 108(H)×64.8(V) mm |
| omrids dim. | 118.5(H)×77.1(V) ×6.37(D) mm |
| bezel område | 110.6(H)×67.4(V) mm |
| behandling | - |
| luminans | 470 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) (TM) |
| visningsretning | - |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/70/50 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K 52% NTSC |
| lyskilde | WLED [3S6P] , With LED Driver |
| vægt | TBD |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | CPU , 40 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
