| Varenummer | AM-800480N3TZQW-57H |
| Mærke | AMPIRE |
| Størrelse | 5.0 |
| Ansøgning | Industrial Automotiv |
| Løsning | 800×480 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | 3S6P |
| Interface | |
| fabrikant | AMPIRE |
| modelnavn | AM-800480N3TZQW-57H |
| skærmstørrelse | 5.0 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 800(RGB)×480 (WVGA) 188PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 108 × 64.8 (H×V) |
| omrids (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| rammeareal (mm) | 109.6 × 66.4 (H×V) |
| behandling | - |
| luminans | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 30 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| farvedybde | 262K |
| baggrundsbelysning | 3S6P WLED , 50K hours , With LED Driver |
| masse | - |
| anvendes til | Industrial Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
